A-Starjet 7702UV LED DIGITAL PRINTER

FOB Reference Price:Get Latest Price
US $5,900-6,000 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Inkjet Printer
Condition:
New
Plate Type:
Roll to Roll
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
A-Starjet UV digital printer
Model Number:
UV LED roll to roll digital inkjet printer
Usage:
Paper Printer, Banner, Leather, Wall paper printer
Automatic Grade:
Semi-Automatic
Color & Page:
CMYK+Optional White
Voltage:
110V/220V
Gross Power:
2500W
Dimensions(L*W*H):
2.84*0.9*1.25 (M)
Weight:
220kg
Certification:
CE
After-sales Service Provided:
Engineers available to service machinery overseas
Supply Ability
Supply Ability:
150 Set/Sets per Month
Packaging & Delivery
Packaging Details
Fumigation-free Wooden Pallet
Printer Dimension(M): W x L x H 2.84 x 0.90 x 1.25 220kg
Packing Dimension(M):W x L x H 2.94 x 0.98 x 0.70 360kg
Port
Shanghai, Nongbo, Guangzhou, Qingdao, Zhuhai
Lead Time :
Within 3 days after payment received
Video Description
A-Starjet 7702/03, 1.8M/70Inch/5.9Feet Printer with DX5, DX7
Specification
ItemA-Starjet 7702A-Starjet 7703
Print HeadTwo DX7 Print HeadsThree DX7 Print Heads
Color4 Color:KCMY/KCMY+White Ink Optional
Resolution1440Dpi(Max)
Height of Head2-5mm
Size of Ink Droplet1.5-21pl
Printing Width1700mm1700mm
Media Width1900mm1900mm
Speed3 pass30.7m²/hour44m²/hour
4 pass23.6m²/hour33.7m²/hour
6 pass15/hour24m²/hour
8 pass11.5m²/hour16m²/hour
Feeder/Take upStandard Feeder/Speed and Torque Controllable Take Up System
Payload100kgs100kgs
Heating System

Print Heater and Post Heater with PID Temperature Control

Heater is Suggested Even for UV

InkLED UV
Ink Cartridge8× 350ml ink cartridges12× 350ml ink cartridges
RIP SoftwareIprint 3.8.2/Optional Photoprint, Wasatch, Onyx, SDK Available
PC SystemWin XP & Win 7
Power VoltageAC220-24V 50-60Hz or AC110-120V 50-60Hz
EnvironmentTemperature:20-50℃ ,Humidity:40-60%
Printer DimensionW2840× D900× H1250 (mm)
Packing Dimension

W2940× D980× H700 (mm)

Net/Gross Weight220Kgs/360Kgs

Samples Shoot by Iphone 6IMG_5135.JPG



OUR ACHIEVEMENT

Terminator Image(Changzhou) Tech. Co., Ltd was a software developer founded in 2006. It's major R&D developers had  engaged in cutting, printing industry over 10 years before founding the company. In 2008 we built our own factory and launched the A-Starjet series printers. A legend begins...

A-Starjet 7702/03, 1.8M/70Inch/5.9Feet Printer with DX5, DX7

8.2008

A-Starjet 5.5

The first eco-solvent printer in

China.

2010

A-Starjet 5.5L/5L

The first 3.2M eco-solvent printer in the world.

Early 2011

A-Starjet NEO

The most affordable

printer uses DX5 head.

A-Starjet 7702/03, 1.8M/70Inch/5.9Feet Printer with DX5, DX7

July 2012

A-Starjet 77802/L

The first auto calibrate double side printer in the world.

March 2013

A-StarCut Roll to Roll

The first roll to roll label finisher

March 2014

A-Starcut sheet
The first auto sheet-fed label finisher.





After-Sale Service

Efficiency and expreience are what make A-Starjet outstanding.

We provide 15 months guarantee for printer's boards etc.
